Rais Visio 3:1

, ,

Rais Visio 3:1 Three Sided Room Divider Fireplace 7kw

With extra depth and glass on three sides, the distinctive yet discreet insert RAIS Visio 3:1 allows you to enjoy a beautiful fire in two rooms at the same time. The design is elegantly understated in order to enhance the effect of the wood fire. The door opens easily by pushing it upwards. The combustion is highly efficient and the balance of radiant and convected heat allows you to enjoy a comfortable and uniform warmth.

Please note the high efficiency of 80 %.

Technical Data

  • Dimensions (W-D-H)
  • External dimensions (W-D-H) in mm: 514,2-875,5-1368
  • Combustion chamber inner dimensions (W-D-H) in mm: 221-510-446
  • Flue outlet (diameter): 200
  • Distance from centre to the back edge of the top plate in mm: 628,2-490,1-775,3
  • RATED OUTPUT (KW): 8,3
  • Output
  • Heating (at -20°C) in m2: 75-120
  • Efficiency in %: 80
  • Particulates in g/kg: 5,7
  • Weight in kg: 260
  • Distance to flammable material
  • To side wall in mm: 0
  • To back wall in mm: 45
  • To the ceiling in mm: 420
  • To the side in mm: 0
  • To the floor in mm: 150
  • In front of the floor in mm: 300
  • To furniture: 700
